Weld HDPE Geocell

Classification :

keyword:

HDPE Geocell

PRODUCT DETAILS

                                                                                         Weld HDPE Geocell
Introduction

Geogrids can be used for regulating and controlling groundwater. By setting up geogrid chambers of different sizes and shapes, groundwater resources can be effectively collected and stored, providing water for people's daily life and agriculture needs. At the same time, the geocell can also regulate the changes in groundwater level, preventing problems such as groundwater reverse seepage and ground subsidence from occurring.




Performance
Geogrids can also be used for soil improvement and reinforcement. Due to the presence of certain voids and pore structures in geogrids, they can increase soil permeability and aeration, improve soil texture and structure, and enhance soil bearing capacity and tensile strength. This plays an important role in land development and infrastructure construction, which can effectively improve the utilization rate of land and the stability of engineering.


Application

1. Used to stabilize the roadbed of highways and railways.
2. Used for embankments and shallow water channel management that bear the load of gravity.
3. A hybrid retaining wall used to prevent landslides and gravity loads.
4. When encountering soft foundations, using geogrids can greatly reduce construction labor intensity, reduce roadbed thickness, and achieve fast construction speed and good performance, greatly reducing project costs.





Specification



Item Model

Height

(mm)

Welding distance(mm)

Sheet thickness(mm)

Seam peel strength(N)

Expanded Cell Size(mm)

Expanded

panel size (m)

smooth

textured

TGLG-100-330

100

330

1.1

1.5

1420

244X203

2.44X6.15

TGLG-150-330

150

2130

244X203

2.44X6.15

TGLG-200-330

200

2840

244X203

2.44X6.15

TGLG-100-356

100

356

1.1

1.5

1420

259X224

2.56X6.52

TGLG-150-356

150

2130

259X224

2.56X6.52

TGLG-200-356

200

2840

259X224

2.56X6.52

TGLG-100-400

100

400

1.1

1.5

1420

295X250

4X5

TGLG-150-400

150

2130

295X250

4X5

TGLG-200-400

200

2840

295X250

4X5

TGLG-100-445

100

445

1.1

1.5

1420

320X287

2.56X8.35

TGLG-150-445

150

2130

320X287

2.56X8.35

TGLG-200-445

200

2840

320X287

2.56X8.35

TGLG-100-660

100

660

1.1

1.5

1420

488X406

2.44X12.29

TGLG-150-660

150

2130

488X406

2.44X12.29

TGLG-200-660

200

2840

488X406

2.44X12.29

TGLG-100-712

100

712

1.1

1.5

1420

508X475

2.56X13.72

TGLG-150-712

150

2130

508X475

2.56X13.72

TGLG-200-712

200

2840

508X475

2.56X13.72



Factory Appearance
