Soil reinforcement Geotextile
Classification :
keyword:
Geotextile
PRODUCT DETAILS
Soil reinforcement Geotextile
| Product specification |
| Name; Non-woven geotextiles |
| Thickness; 100g-800g |
| Length; 1-6 meters, if there is a unique measurement can be customized |
| Color; White, black, orange, aid customized hues |
Geotextile is a type of fabric made from synthetic or natural fibers. Common geotextile materials include polyester (PET), polypropylene (PP), and polyethylene (PE).
 |
 |
 |
 |
 |
Soil separation: Geotextiles can be used to separate soil from exclusive strata, stopping soil mixing and infiltration. It can structure an isolation layer between soil layers to stop finer particles from getting into the soil layer, thereby retaining soil stability.
Soil reinforcement: Geotextiles can be used for soil reinforcement projects, such as land backfilling, roadbed reinforcement, etc. It can enlarge the electricity and balance of soil, forestall soil sinking and sliding.
Protective cover: Geotextiles can be used to cowl the floor of land such as reservoirs and riverbanks, offering protection. It can stop erosion, put on and tear on the floor of the land, and the influence of water flow.
Soil and water conservation: Geotextiles can be used for soil and water conservation projects, such as riverbank slope protection, soil and water conservation forests, etc. It can restoration the soil, stop it from being washed away with the aid of wind and rain, and preserve the steadiness and sustainable use of water and soil resources.
|
Properties |
Test Method |
Unit |
GXSF150 |
GXSF200 |
GXSF300 |
GXSF400 |
GXSF500 |
GXSF600 |
GXSF800 |
GXSF1000 |
|
Tensile Strength(MD/TD) |
ASTM D4595 |
kN/m |
8 |
11 |
20 |
24 |
28 |
34 |
48 |
50 |
|
Tensile Elongation(MD/TD) |
ASTM D4595 |
% |
50 |
60 |
60 |
60 |
60 |
60 |
60 |
60 |
|
Grab Tensile Strength(MD/TD) |
ASTM D4632 |
N |
520 |
700 |
1100 |
1500 |
1800 |
2200 |
2800 |
3000 |
|
Grab Elongation(MD/TD) |
ASTM D4632 |
% |
50 |
50 |
60 |
60 |
60 |
60 |
60 |
60 |
|
Trapezoidal Tear Strength(MD/TD) |
ASTM D4533 |
N |
220 |
330 |
400 |
480 |
560 |
620 |
860 |
880 |
|
CBR Burst Strength |
ASTM D6241 |
N |
1700 |
2400 |
3200 |
4300 |
5300 |
6000 |
6800 |
7000 |
|
Pore Size O90 |
ASTM D4751 |
µm |
90 |
85 |
80 |
75 |
70 |
60 |
55 |
50 |
|
Water Flow Q100 |
ASTM D4491 |
L/m2/s |
160 |
145 |
140 |
120 |
105 |
95 |
90 |
80 |
|
Weight |
ASTM D5261 |
g/m2 |
150 |
200 |
300 |
400 |
500 |
600 |
800 |
1000 |
Vegetation coverage: Geotextiles can be used in aggregate with vegetation for vegetation insurance projects. It can enlarge the soil temperature and humidity for plant growth, offering a right surroundings for plant growth.
Engineering protection: Geotextiles can additionally be used for engineering protection, such as pipelines and geotechnical engineering. It can play a function in waterproofing, anti-seepage, and anti extrusion, defending the balance and security of engineering structures.
 |
 |
 |
 |
 |
geotextiles have a wide range of applications in civil engineering, environmental engineering, and agriculture, providing functions such as soil separation, soil reinforcement, protective coverage, and soil and water conservation, protecting the stability and sustainable development of land and environment.
Q: What can you buy from us?
A: Geomembrane,Geogrid,Geocell, Geotextile, Geocomposite,
Q: Can I have a sample?
A: Yes. And sample free.
Q: What's the payment terms?
A: T/T or L/C. Others could be negotiated.
Q: What's the delivery time?
A: 3-20 days after confirming order, detail delivery date should be decided according to production season and order quantity.
Factory Appearance
