50/50kn Black Fiberglass Customized Geogrid Pet Fiberglass Composite Glassfiber Geogrids

Classification :

keyword:

Geocomposite

PRODUCT DETAILS

Composite geogrid is a civil engineering material commonly used in earthwork and hydraulic engineering. It is usually made of high-strength polymer materials, which have good load-bearing capacity and compressive performance. Composite geogrids have the characteristics of strong structure, corrosion resistance, and easy installation, which can effectively enhance the stability of soil, prevent soil erosion, and improve the drainage performance and impermeability of soil. Widely used in the construction and reinforcement of roads, bridges, embankments, reservoirs, and other engineering projects.

  1. Road construction: used to enhance the bearing capacity of soil, prevent roadbed settlement and deformation, and improve the stability and durability of the road surface.
  2. Hydraulic engineering: used in hydraulic engineering such as embankments, river embankments, reservoirs, etc., to enhance the anti erosion ability of soil and prevent erosion and collapse of soil slopes.
  3. Soil erosion control: used to prevent soil erosion, prevent land and river debris flows, protect slopes along rivers, and carry out greening projects.
  4. Landscape engineering: used for fixing and supporting lawns and flower beds to prevent soil erosion and collapse.
  5. Mining engineering: used for backfilling and reinforcement of mines, reducing environmental pollution and safety hazards caused by mine collapse.

Overall, composite geogrids play an important role in various engineering projects, effectively reinforcing soil, preventing erosion, and improving the stability and durability of the project.





Property unit BC50/D200 BC63/D200 BC70/D200 BC80/D200 Test Standard
Geocomposite specification
Hydraulic
conductivity(MD)
M²/s 2.8×10-3 3.2×10-3 4.0×10² 5×10-3 ASTM D4716
Puncture KN/m 0.17 0.17 0.17 0.17 ASTM D7005
Resistance
Core Material Geonet Specification
Thickness  mm 6.3 7.0 8.0 9.0 ASTM D5199
Density g/cm³ 0.94 0.94 0.94 0.94 ASTM D1505
Carbon Black Content  % 2 2 2 2 ASTM D1603
Tensile strength (MD) KN/m 8.0 10.0 12.0 14.0 ASTM D7179
Geotextile Specification
Unit weight g/m2 200 200 200 200 200
Geotextile type    Continuous filament non-woven geotextile



Factory Appearance
