Construction engineering Geotextile fabric
Classification :
keyword:
Geotextile
PRODUCT DETAILS
Construction engineering Geotextile fabric
Product specification
Name; Non-woven geotextiles
Thickness; 100g-800g
Length; 1-6 meters, if there is a special size can be customized
Color; White, black, orange, support custom colors
Filament non-woven geotextile, with high strength, strong anti-needling ability, corrosion resistance, acid and alkali resistance, aging resistance and other functions.
1. For reinforcement in the backfill of retaining wall, or for anchoring the panel of retaining wall. Construction of wraparound retaining walls or abutments.
2. Strengthen the flexible pavement, repair the cracks on the road, prevent soil erosion and freezing damage of the soil at low temperature.
3. Drain the filter layer around the dark pipe or the gravel drainage ditch.
4. Filter layer of water Wells, relief Wells or baroclinic pipes in water conservancy projects.
|
Properties |
Test Method |
Unit |
GXSF150 |
GXSF200 |
GXSF300 |
GXSF400 |
GXSF500 |
GXSF600 |
GXSF800 |
GXSF1000 |
|
Tensile Strength(MD/TD) |
ASTM D4595 |
kN/m |
8 |
11 |
20 |
24 |
28 |
34 |
48 |
50 |
|
Tensile Elongation(MD/TD) |
ASTM D4595 |
% |
50 |
60 |
60 |
60 |
60 |
60 |
60 |
60 |
|
Grab Tensile Strength(MD/TD) |
ASTM D4632 |
N |
520 |
700 |
1100 |
1500 |
1800 |
2200 |
2800 |
3000 |
|
Grab Elongation(MD/TD) |
ASTM D4632 |
% |
50 |
50 |
60 |
60 |
60 |
60 |
60 |
60 |
|
Trapezoidal Tear Strength(MD/TD) |
ASTM D4533 |
N |
220 |
330 |
400 |
480 |
560 |
620 |
860 |
880 |
|
CBR Burst Strength |
ASTM D6241 |
N |
1700 |
2400 |
3200 |
4300 |
5300 |
6000 |
6800 |
7000 |
|
Pore Size O90 |
ASTM D4751 |
µm |
90 |
85 |
80 |
75 |
70 |
60 |
55 |
50 |
|
Water Flow Q100 |
ASTM D4491 |
L/m2/s |
160 |
145 |
140 |
120 |
105 |
95 |
90 |
80 |
|
Weight |
ASTM D5261 |
g/m2 |
150 |
200 |
300 |
400 |
500 |
600 |
800 |
1000 |
Geotextile packaging
Geotextiles are packaged in rolls. The fixed length value is determined according to the product specification or through negotiation between the parties concerned.
Support customization; Specification, length, manufacturer name, production date, inspection responsibility stamp, etc.
Factory Appearance
