PRODUCT DETAILS

Anti leakage Geomembrane

Name; geomembrane

Length; 1-6m

Thickness; 0.3 -2 mm

Material; HDPE, LDPE, PVC, LLDPE

Color; Black, white, blue, customized products can be supported according to customer needs

Geomembrane is a waterproof and leak proof material, generally made of high molecular weight polymers. Commonly used materials include polyethylene (PE) and polyvinyl chloride (PVC).

Geomembrane is a fabric used for soil and groundwater protection, which has the following functions:

Preventing soil erosion: Geomembranes can serve as an fine barrier to stop the erosion and erosion of soil by way of water and wind, keeping soil integrity and stability.

Anti leakage: Geomembrane has sturdy water resistant performance, which can successfully stop water from leaking into the floor via the soil layer, warding off waste and air pollution of groundwater resources.

Soil separation: Geomembranes can be used to separate soil from high-quality layers, supply up soil mixing and infiltration, and maintain the integrity of the ground structure.

Culvert and tunnel engineering: Geomembranes can be used as water resistant layers in culvert and tunnel engineering to cease groundwater from infiltrating the indoors of caves or tunnels.

Sewage treatment: Geomembrane can serve as an anti-seepage layer in sewage treatment facilities, stopping sewage from leaking to the underground ground.

Isolation function: Geomembranes can isolate soil layers with exceptional properties, forestall mixing between exclusive soil layers, and make sure the zoning and layered use of the land.

Ensure engineering quality: The use of geomembranes can efficaciously enhance the pleasant and balance of the project, shield the soil shape and infrastructure from unfavourable elements such as floor expansion, settlement, erosion, and corrosion.

Promoting plant growth: Geomembranes can minimize the evaporation and loss of soil moisture, supply moisturizing and insulation effects, and furnish proper environmental prerequisites for plant growth.

Properties	Test Method	GMSH050	GMSH075	GMSH100	GMSH150	GMSH200
■ Thickness	ASTM D5199	0.50 mm	0.75 mm	1.00 mm	1.50 mm	2.00 mm
■ Density	ASTM D1505	0.940 g/cc	0.940 g/cc	0.940 g/cc	0.940 g/cc	0.940 g/cc
Tensile Properties
■ Yield strength ■ Break strength ■ Yield elongation ■ Break elongation	ASTM D6693 Type IV	7 kN/m 13 kN/m 12% 700%	11 kN/m 20 kN/m 12% 700%	15 kN/m 27 kN/m 12% 700%	22 kN/m 40 kN/m 12% 700%	29 kN/m 53 kN/m 12% 700%
■ Tear Resistance	ASTM D1004	62 N	93 N	125 N	187 N	249 N
■ Puncture Resistance	ASTM D4833	160 N	240 N	320 N	480 N	640 N
■ Stress Crack Resistance	ASTM D5397	500 hrs	500 hrs	500 hrs	500 hrs	500 hrs
■ Carbon Black Content	ASTM D1603	2.0%	2.0%	2.0%	2.0%	2.0%
■ Carbon Black Dispersion	ASTM D5596	For 10 different views:9 in Categories 1 or 2 and 1 in Category 3
■ Oxidative Induction Time (OIT)	ASTM D3895	100 min.	100 min.	100 min.	100 min.	100 min.
■ UV Resistance High Pressure OIT retained after 1600hrs	ASTM D5885	50%	50%	50%	50%	50%
Dimensions
■ Roll Width (m)		7	7	7	7	7
■ Roll Length (m)		420	280	210	140	105

Q: What can you buy from us?

A: Geomembrane,Geogrid,Geocell, Geotextile, Geocomposite,

Q: Can I have a sample?

A: Yes. And sample free.

Q: What's the payment terms?

A: T/T or L/C. Others could be negotiated.

Q: What's the delivery time?

A: 3-20 days after confirming order, detail delivery date should be decided according to production season and order quantity.

Applied to the projects of Landfill site, bank, dam, storage reservoir, channel, irrigation, highway, railway, tunnel, drinking tank, salt field bittern pan, chemical liquid storage, treatment tank, artificial lake and riverway etc.

Factory Appearance
