PET PP 350g Non Woven Geotextile Road infrastructure Landscape Fabric for Garden and Lawn

Classification :

keyword:

Geotextile

PRODUCT DETAILS



Product specification
Name; Non-woven geotextiles
Thickness; 100g-800g
Length; 1-6 meters, if there is a unique measurement can be customized
Color; White, black, orange, aid customized hues

Polyester Continuous Filament Needlepunched Nonwoven Geotextile Is made from virgin PET (polyester) chips, the continuous filament was extruded from PET chip by machine directly by spunbond process, and then punch together to get the stable 3D with higher strength fabric. So it has high strength, good creep property excellent and erosion resistance, aging-resistance and heat resistance,Separation, filtration, drainage, protection and reinforcement functions. improve the load bearing capacity of a specific soil structure, such as the reinforcement of a retaining wall.

  1. Use the good air permeability and water permeability of geotextiles to allow water to pass through, thereby effectively intercepting sand and soil loss;
  2. Geotextile has good water conductivity. It can form drainage channels inside the soil to drain excess liquid and gas out of the soil structure;
  3. Use geotextiles to enhance the tensile strength and deformation resistance of the soil and enhance the stability of the building structure to improve the quality of the soil;
  4. Effectively diffuse, transfer or decompose concentrated stress to prevent soil from being damaged by external forces;
  5. Prevent the mixing of sand, soil and concrete between the upper and lower layers;
  6. The mesh is not easy to block because the network structure formed by the amorphous fibrous tissue is adaptable and mobile.
  7. High water permeability: It can still maintain good water permeability under the pressure of soil and water;



Properties

Test Method

Unit

GXSF150

GXSF200

GXSF300

GXSF400

GXSF500

GXSF600

GXSF800

GXSF1000

Tensile Strength(MD/TD)

ASTM D4595

kN/m

8

11

20

24

28

34

48

50

Tensile Elongation(MD/TD)

ASTM D4595

%

50

60

60

60

60

60

60

60

Grab Tensile Strength(MD/TD)

ASTM D4632

N

520

700

1100

1500

1800

2200

2800

3000

Grab Elongation(MD/TD)

ASTM D4632

%

50

50

60

60

60

60

60

60

Trapezoidal Tear Strength(MD/TD)

ASTM D4533

N

220

330

400

480

560

620

860

880

CBR Burst Strength

ASTM D6241

N

1700

2400

3200

4300

5300

6000

6800

7000

Pore Size O90

ASTM D4751

µm

90

85

80

75

70

60

55

50

Water Flow Q100

ASTM D4491

L/m2/s

160

145

140

120

105

95

90

80

Weight

ASTM D5261

g/m2

150

200

300

400

500

600

800

1000





Q: What can you buy from us?

A: Geomembrane,Geogrid,Geocell, Geotextile, Geocomposite,

Q: Can I have a sample?

A: Yes. And sample free.

Q: What's the payment terms?

A: T/T or L/C. Others could be negotiated.

Q: What's the delivery time?

A: 3-20 days after confirming order, detail delivery date should be decided according to production season and order quantity.

Anti freezing Geotextile fabric



Factory Appearance
